Semi-automatic Paper Bag Machine

Low investment · Fast changeover · Small batch & variety

Product Categories

If you need special sizes, please consult experts online

1200F

Semi-Automatic Paper Bag Tube Forming Machine

Feeding Method: Automatic Feeder
Paper Weight: 180-350 gsm
Bag Width Range: 150-460 mm
Speed: 70-100 bags/minute

50A

Semi-Automatic Paper Bag Bottom Gluing and Sealing Machine

Feeding Method: Automatic Feeder
Paper Weight: 120-350 gsm
Bag Width Range: 150-450 mm
Speed: 70-100 bags/minute

35D/45D

Semi-Automatic Paper Bag Bottom Opening and Gluing Machine

Feeding Method: Automatic Feeder
Paper Weight: Kraft Paper 150-250 gsm; White Cardboard /
Grey Board (with PP Lamination) 180-250 gsm
Bag Width Range: 180-400 mm
Max.Bottom Card Size: 150 x 390 mm (5.90 x 9.84 inch)
Min.Bottom Card Size: 60 x 170 mm (2.36 x 6.69 inch)
Speed: 50-80 bags/minute

350C

Semi-Automatic Paper Bag Bottom Card Pasting Machine

Feeding Method: Automatic Feeder
Paper Weight: 120-350 gsm
Bag Width Range: 150-450 mm
Speed: 70-100 bags/minute

Semi-Automatic Production Line Combination

For customers wishing to establish a small-scale paper bag production line from scratch, equipment can be assembled according to the following process.

From Flat Sheet to Tube (Forming)
Insert Bottom Card for Reinforcement
Glue and Seal Bottom

What's the difference between semi-automatic and fully automatic paper bag machines?

Semi-automatic machines require manual intervention for tasks like paper feeding and adjustments but automate key processes like forming, cutting, and gluing. They are ideal for small-batch, multi-variety production with lower investment compared to fully automatic systems.

What is the typical production speed of a semi-automatic machine?

Semi-automatic machines typically produce 20–40 bags per minute, depending on the model and operator skill level—making them suitable for small to medium production volumes.

How long does it take to change over between different bag sizes?

Changeover on semi-automatic equipment typically takes 10–20 minutes, as adjustments are made manually without complex programming—ideal for frequent size changes and diverse order types.

How many operators are needed to run a semi-automatic machine?

The 1200F handbag forming machine requires 1–2 operators, the 50A bottom gluing machine requires 1 operator, and the 350C bottom card machine requires 1 operator. These can be operated individually or combined into a small production line.

Can semi-automatic machines produce bags with bottom cards?

Yes. By combining the 1200F (forming) with the 350C (bottom card placement) and 50A (bottom gluing), you can produce reinforced bottom bags with card reinforcement for premium applications.

What is the typical return on investment for semi-automatic equipment?

Depending on order volume and labor cost savings, semi-automatic equipment typically pays back in 3–8 months. The 1200F alone can pay back in 3–6 months, while a full combination line (1200F + 350C + 50A) typically pays back in 6–10 months.

Start Your Intelligent Bag Making Journey

Tell us your requirements, and KORO will recommend the most suitable fully automatic paper bag machine solution for you.

Solutions Tailored to Your Needs

We listen to market demands, transforming challenges into customized solutions—from complete production lines to core components—to craft equipment that seamlessly integrates with your production processes.

Integrated Inline Production Full-Range Size Support Patented Linear Structure Start Your Personalization
